Warn ZEON 10 PLATINUM winch kit for TOYOTA J15 2.8L D4D FROM 2018
Payment Methods
Your payment information is processed securely. We do not store any credit card details and do not have access to your credit card information.
Product Information
The premium kit with WARN ZEON 10 Platinum sets new standards in terms of power, durability and reliability . This winch is specially designed for everyday use and offers the highest performance for commercial and private applications.
Scope of delivery and important information
Included in the Premium Kit :
-
Socket extension for flexible positioning of the cable remote control
-
roller cable window cover for additional safety
Please note that optional accessories such as radio remote control, plastic rope and the matching aluminum cable window must be ordered separately.
Assembly and safety instructions
-
Assembly time : approx. 300 minutes (without electrics)
-
TÜV parts certificate : Yes
-
Screw set included : Yes
-
Coating : KTL/powder in RAL9005 black satin
road safety
If the mounting kit is used in public road traffic in conjunction with a steel cable and roller cable window (unless excluded by a TÜV certificate), a cover with the RSF Cover 15-905(E) is required.
PREMIUM LEVEL – Power meets durability
Our premium series stands for maximum resilience and long-lasting performance . These cable winches are the ideal companions for demanding applications, whether commercial or private . Safety and reliability are our top priority!
Technical details of the WARN ZEON 10 Platinum winch
| Characteristic | details |
|---|---|
| Model | WARN ZEON 10 Platinum |
| Tension | 12 volts |
| traction | 4,536 kg |
| steering | contactor |
| radio remote control | Yes, extended |
| cable remote control | No |
| transmission | 3-stage planetary gear |
| translation | 162:1 |
| brake | Automatically |
| drum dimensions | 8 x 22.9 cm |
| Weight | 48 kg |
| rope material | Steel |
| rope length | 24 mx 9.5 mm |
| battery cable | 1.83 m |
| cable freewheel | Electric |
| cable window | roller cable windows |
| Min. cold start current battery | 650 CCA |
| tow hook | Yes |
| fastening screws | Yes |
| Dimensions (L x D x H) | 615.9 x 181.6 x 266.8 mm |
| hole pattern | 254 x 114.3 mm |
